Description: 32 IP channel max, up to 12MP resolution
Max 32MP, Record Rate 384 Mbps
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG
2x HDMI/ 2x VGA
4 SATA interface up to 16TB
2 RJ-45 port (10/100/1000Mbps), 1x eSATA
16/6 alarm I/O, RS232, 4x USB, RS485
1.5U 19” chassis, no front panel control, mouse included
Other brands IP cameras supported: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek and etc., ONVIF 21.12(Profile T; Profile S; Profile G); CGI; SDK
2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus
Free IP monitoring software available
Vendor Homepage: www.dahuasecurity.com/products/All-Products/Network-Recorders/WizSense-Series/NVR-5-EI-Series/4HDD/NVR5432-EI
Number of Channels: 32
Number of drives/bays: 4
Desktop/pedestal: Yes
Rack 1.5U: Yes
CPU: Industrial-grade processor
SATA: Yes
Integrated LAN: Gigabit
15pin D-sub: 2
Alarm In: 16
Alarm Out: 6
HDMI: 2
RJ45: 2
RS232: 1
RS-485: 1
USB 2.0: 4
Power supply requirements: 100–240 VAC, 50-60 Hz
Power consumption: 13
Dimensions: 440.0 × 415.1 x 70.0mm
Shipping box quantity: 1
Shipping Box Depth: 52.5
Shipping Box Height: 20.5
Shipping Box Weight: 6.55
Shipping Box Width: 50
Unit Brutto Volume: 0.05381
Unit Net Weight: 4.74
Unit Gross Weight: 6.55
CnCode: 85219000
Unit Box Width: 0.5
Unit Box Length: 0.525
Unit Box Height: 0.205
Full Description Line: Channels 32|Drives/bays 4|Desktop/pedestal|Rack 1.5U|CPU Industrial-grade processor|SATA|Integrated LAN Gigabit|2x15pin D-sub|2xHDMI|1xRS232|4xUSB 2.0|2xRJ45|1xRS-485|16xAlarm In|6xAlarm Out|Power supply requirements 100–240 VAC, 50-60 Hz|Power consumption 13 Watts|Dim. 440.0 × 415.1 x 70.0mm
Category Code: NVR
