Engineered to handle high-intensity workloads with proven technology
Ultrastar Data Center HC555 hard drives are engineered to deliver the large capacity, strong performance and proven reliability needed to handle high-intensity workloads in 24×7 multi-user data center environments.
Handle Data Center Workloads with Proven Technology
The combination of field-proven hardware with the latest innovative technologies delivers the performance, capacity and reliability needed to handle high-intensity workloads in 24×7 multi-user data center environments.
Grow Capacity while Lowering Costs
Western Digital’s energy-assisted perpendicular magnetic recording (ePMR) technology enables customers to grow capacities while lowering TCO (total cost of ownership) including both $/TB and OpEx.
Rapid qualification and integration
Leveraging hardware designs from generations of highly successful products ensures easy qualification, seamless integration and rapid adoption by existing customers.
Reliability You Can Trust
Built off the same platform that is deployed in thousands of data centers around the world, these drives deliver superior dependability and field-proven reliability for hassle free data storage.
Increase Density with Low Power
Western Digital’s Triple-Stage Actuator (TSA) increases tracks-per-inch (TPI) while providing greater control over the actuator arm, enabling the highest capacities with low power.
Meet Eco Goals with Helium
The stable internal environment created by our HelioSeal® technology enables this high-capacity helium drive to deliver one of the lowest power profiles in the industry.
Protected Against Vibration & Shock
Disturbances caused by increased vibration are anticipated and proactively counteracted by Rotation Vibration (RV) sensors and subtle shock events are automatically detected by multi-axis shock sensors and compensated for with dynamic fly height technology to maintain performance and protect data.
Trusted Reliability, Quality and World-Class Support
As an industry-leading hard drive manufacturer, Western Digital stands behind their Ultrastar hard drives with the assurance of a projected 2.5M-hour MTBF rating.
- Capacities up to 20TB in standard 3.5-inch form factor
- Conventional Magnetic Recording (CMR) technology
- Superior reliability of field-proven hardware and firmware designs
- Seamless integration with existing applications & environments
Specifikacijos
| Vendor Homepage | https://www.westerndigital.com/en-in/products/internal-drives/data-center-drives/ultrastar-data-center-hc555-hdd?sku=0B47747 |
|---|---|
| Category Code | HES |
| Unit Box Height | 0.028 |
| Unit Box Length | 0.15 |
| Unit Box Width | 0.105 |
| 24/7 operation | Yes |
| Average latency | 4.16 ms |
| Component for | Server/workstation |
| HDD average transfer rate | 269 MB/s |
| HDD capacity | 16000 GB |
| HDD interface transfer rate | 6 Gbit/s |
| HDD size | 3.5 " |
| HDD speed | 7200 RPM |
| HDD sustained transfer rate | 257 MiB/s |
| Hot-swap | No |
| Interface | Serial ATA III |
| Mean time between failures (MTBF) | 2500000 h |
| Start/stop cycles | 600000 |
| Storage drive buffer size | 512 MB |
| Type | HDD |
| Operating voltage | 5 / 12 V |
| Power consumption (idle) | 5.3 W |
| Power consumption (typical) | 6.4 W |
| Non-operating shock | 250 G |
| Non-operating vibration | 1.04 G |
| Operating shock | 50 G |
| Operating temperature (T-T) | 5 - 60 °C |
| Operating vibration | 0.67 G |
| Storage temperature (T-T) | -40 - 70 °C |
| Depth | 147 mm |
| Height | 26.1 mm |
| Weight | 679 g |
| Width | 101.6 mm |
| Warranty period | 5 year(s) |
| HDD Family name | Ultrastar DC HC555 |
| Model name | Western Digital Ultrastar DC HC555 |
| Units per Pallet | 0 |
| Units per Shipping Box | 20 |
| Unit Calculated Volume | 0.001446 cubm |
| Product Net Weight | 0.69 kg |
| Unit Calculated Weight | 0.715 kg |
