Indoor/outdoor, 4x4 WiFi 6 access point designed for mesh applications.
The Access Point WiFi 6 Mesh (U6 Mesh) is a high-performance, four-stream WiFi 6 access point that provides best-in-class signal meshing to enhance the wireless coverage of home and enterprise networks. The U6 Mesh can reach an aggregate throughput rate up to 5.3 Gbps with its 5 GHz (4x4 MU-MIMO and OFDMA) and 2.4 GHz (2x2 MIMO) bands. This access point also operates at full 4x4 MIMO with 160 MHz channels to create high-capacity wireless uplinks and facilitate faster data transfer. The sleek U6 Mesh is discreet enough to stage anywhere in your home or office, but also rugged enough to reliably operate outdoors thanks to its IPX5-rated, waterproof housing. The U6 Mesh is a plug-and-play device designed to easily extend your wireless signal to ensure full, seamless coverage and high-quality WiFi connectivity. It can be set up in minutes and fully managed with the UniFi Network web application or mobile app.
- High-efficiency 4x4 WiFi 6 (802.11ax)
- 5 GHz (4x4 MU-MIMO and OFDMA) band with a 4.8 Gbps throughput rate
- 2.4 GHz (2x2 MIMO) band with a 573.5 throughput rate
- Operates at full 4x4 MIMO with 160 MHz bandwidth
- Powered with 802.3af PoE (PoE adapter included)
Specifikacijos
| Summary | Ubiquiti U6-Mesh. 2.4 GHz, 5 GHz, Maximum data transfer rate: 4800 Mbit/s. Security algorithms: WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3. Ethernet LAN data rates: 1000 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 11.4 W |
|---|---|
| Vendor Homepage | https://eu.store.ui.com/ |
| Category Code | WAP |
| Unit Box Height | 0.098 |
| Unit Box Length | 0.185 |
| Unit Box Width | 0.125 |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Bluetooth | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 1000 Mbit/s |
| Frequency band | 2.4 - 5 GHz |
| Maximum data transfer rate | 4800 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 573.5 Mbit/s |
| Maximum data transfer rate (5 GHz) | 4800 Mbit/s |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Networking standards | IEEE 802.11a/IEEE 802.11ac/IEEE 802.11ax/IEEE 802.11b/IEEE 802.11g/IEEE 802.11n/IEEE 802.1Q/IEEE 802.3af |
| Quality of Service (QoS) support | Yes |
| VLAN support | Yes |
| Security algorithms | WPA/WPA2/WPA3/WPA-Enterprise/WPA-PSK |
| Ethernet LAN (RJ-45) ports | 1 |
| AC input voltage | 44 - 57 V |
| Input current | 0.32 A |
| Power consumption (max) | 11.4 W |
| Power over Ethernet (PoE) | Yes |
| Housing material | Aluminium,Plastic |
| International Protection (IP) code | IPX5 |
| LED indicators | Yes |
| Placement | Ceiling,Pole,Table,Wall |
| Product colour | White |
| Reset button | Yes |
| Antenna gain level (max) | 5 dBi |
| Antenna type | Internal |
| Depth | 48.5 mm |
| Height | 159.5 mm |
| Weight | 400 g |
| Width | 48.5 mm |
| PoE adapter included | Yes |
| Quantity per pack | 1 pc(s) |
| Operating relative humidity (H-H) | 5 - 95 % |
| Operating temperature (T-T) | -30 - 60 °C |
| Harmonized System (HS) code | 85176990 |
| Model | U6-MESH |
| Model name | U6-Mesh |
| Units per Pallet | 0 |
| Units per Shipping Box | 8 |
| Unit Calculated Volume | 0.006048 cubm |
| Unit Calculated Weight | 1.03 kg |
